TECHNICAL DATA

ELARGO MODELS

SERIES FEATURES

ELARGO – Beauty and the Beat

□

drop-shaped, acoustically advantageous enclosure
□

GAUDER Akustik XPulse drivers
□

Midrange driver in closed enclosure
□

Beryllium tweeter, upgradeable to diamond tweeter
□

Symmetrical, ultra-steep crossover
□

Integrated TDC Time Delay Control
□

Steep filters > 50 dB/octave
□

exclusively components from Mundorf, IT and WBT

□
Bass Extension System
□

adjustable bass volume in three stages
(-1.5 dB, linear, +1.5 dB)
□

WBT BiWiring binding posts
□

Clearwater internal wiring
□

large, easily adjustable stand
□

Front-grille with magnetic holder optionally available

	Elargo 100	Elargo 200
Construction	3-way bass-reflex speaker, floorstanding speaker	3-way bass reflex speaker, floorstanding speaker
Impedance [Ohm]	4	4
Power handling [W]	280	480
Height [cm]	119	126
Width [cm]	26	30
Depth [cm]	38	43
Weight [kg]	40	50

	Elargo 100	Elargo 200	Elargo Center
Bauweise	3-Wege-Bassreflexbox Standlautsprecher	3-Wege-Bassreflexbox Standlautsprecher	xxxxx
Impedanz [Ohm]	4	4	4
Belastbarkeit [Watt]	280	180	190
Höhe [cm]	119	126	x
Breite [cm]	26	30	x
Tiefe [cm]	38	43	x
Gewicht [kg]	40	50	x

Elargo 100

3-way bass-reflex speaker with two 7” XPulse special long-throw bass drivers with rear-ventilated centering spider and stiffened aluminum cone. Down-firing principle for even room excitation. XPulse midrange driver with lightweight, damped, ultra-stiff aluminum cone, powerful drive and rear-ventilated centering spider. Tweeter with ultra-light beryllium dome and iron-neodymium-boron magnet for extremely high treble resolution (perfect transient response), upgradeable to diamond.

Elargo 200

3-way bass-reflex speaker with two 22 cm XPulse special long-throw bass chassis with rear-ventilated centring spider and stiffened aluminium cone. Down-firing principle for even room excitation. XPulse midrange driver with lightweight, damped, ultra-stiff aluminum cone, powerful drive and rear-ventilated centering spider in a closed midrange cabinet. Tweeter with ultra-light beryllium dome and iron-neodymium-boron magnet for extremely high treble resolution (perfect transient response), upgradeable to diamond.

Finishes

Piano lacquer black

Rosewood high gloss

Available in piano lacquer black and in rosewood high gloss
